Easy installation - Huge improvements
The Boost Cooler Water Injection kit allows you by active cooling of the combustion to increase the boost pressure and ignition timing safely and without exposing the engine higher thermal load. Power losses at higher ambient temperatures are greatly compensated. Water Injection also reduces the specific fuel consumption as also lowers the exhaust gas temperature (EGT).
The Boost Cooler injection works in three ways: Firstly, when water is injected into the intake system prior to the cylinder head, the small droplets absorb heat from the intake air. When we apply heat energy to it, its molecules begin to expand: a great deal of heat is absorbed during this process owing to water’s specific heat capacity - approximately 4.2kJ/(kg.K). Next, the small droplets of water start to evaporate. And so the intake air charge is cooled still further (up to 60°C and more).bkühlt und verdichtet. Zudem wird auch der Brennraum aktiv gekühlt (in-cylinder-cooling).
Finally, when the remaining water droplets and water vapour reach the combustion chamber, steam is produced. When the water changes from the liquid to gas state, large amount of heat energy is consumed in sustaining the process. The latent heat of evaporation is 2256kJ/kg, approx. six times more than gasoline.
This chemical process acts as an anti-detonant and also keeps the interior of the engine very clean, so preventing the build-up of carbon “hot spots”. So water is the perfect liquid for regulating excess heat under certain engine-operating conditions and you´ll cool down your EGT, the valves, pistons and turbocharger!
with Water Injection
High-quality stainless steel braided line for your Boost Cooler Water Injection of the ProLine Series or compatible Water-Methanol Injection Systems. This is the highest quality level of connection technology we can offer. Stainless Steeel lines from SNOW Performance are quality products at the highest level. Ideally suited for high demands on optics and safety, in motorsport as well as marine and aviation applications.
More Power & Torque
with Boost Cooler Water Injection
Especially with already tuned engines, the thermal load is considerably reduced and prevents knocking combustion. When injecting a 50/50 mix of water-alcohol the effective octane of your fuel will increase approx. 20-25 points. Turning ordinary 95 octane pump gas to 116 Race Gas Quality fuel.
The Boost Cooler Water/Meth-system is compatible with NOS, LPG/Autogas and bioethanol (E85) applications.
